Digital Turns Tester for Toroidal Coils and Current Transformers(Turns - TTPT)





























  • Video Demo
  • Description
  • Specification
  • Advantages
  • Buy Now









This equipment is specially designed for measuring Turns, Polarity and DC Resistance for Toroidal Coils, Current Transformers, Ring Core Coils or Transformers.

This equipment is similar to our TURNS-LCRTZ , but it can only measure TURNS , POLARITY & DC Resistance.

Ideal for counting number of Turns for Toroidal Coils / Current Transformers / Current Sensors / Ring Core Coils.

Measurement Parameters : Turns, Polarity and DC Resistance

Test frequency : 50Hz, 100Hz, 500Hz, 1KHz, 5KHz, 10KHz

Click on Data Sheet TURNS-TTPT

Measurement  Freq.  50Hz, 100HZ, 500Hz, 1KHz, 5KHz,10 KHz
Measurement Voltage  0.1 V ~ 1.0 V RMS (@ 50 mV increment)
Four Terminal or Kelvin Test  For eliminating  lead resistance.
Res. (Rdc)  0.01Ohm ~ 20KOhm
TTPT-100
(Toroidal Turns Test Platform)
5 Turns ~ 1000 Turns
TTPY-1000
(Toroidal Turns Test Platform)
500 Turns ~ 10,000 Turns
TURNS + 0.2% + 0.5 T for high and  medium permeability cores at suitable test frequency.
Internal  Diameter  must be able to pass a wire as thin as 0.2 mm.  External Diameter as high as 200 mm.
Power requirement  110 ~ 230 Vac / 50 ~ 60 Hz AC



Key Benefits

  • Turns Range 1 (TTP1)    : 5 Turns ~ 1000 Turns by Using Toroidal Turns Test Platform (TTPT-100 )
  • Turns Range 2 (TTP2)    : 500 Turns ~ 10,000 Turns by Using Toroidal Turns Test Platform (TTPT-1000 )
  • Polarity                            :  Reverse Polarity is indicated as (-ve) singe while measuring Turns
  • DC Resistance                : 0.01 Ohm ~ 20 KOhm

You can Buy Digital Turns Tester for Toroidal Coils and Current Transformers using Paypal Account

TURNS-TTPT
